Worldwide shipping cost via DHL:
For one controller — $90.
For two controllers and more — ask.

For the controller setup, you need an On-board computer or USB2CAN module. Manual.

Tech specs:

• max power 27kW
• max phase current 500A
• max battery current 350A
• max battery voltage 90V
• dimensions 205х98х50 mm
• weight 1440 g

In the kit:

• Сontroller P24F with compound potting and the latest firmware.
• CAN-wire 120 cm (47.2 inch) for connection to the On-board computer.
• Covers for battery and phase wires with screws — 2 pcs.
• Screws for M6 terminals of phase wires — 3 pcs.
• Screws for M6 terminals of battery wires — 2 pcs.
• Pins for crimping JWPF connectors — 22 pcs.
• JWPF 6P connector — 4 pcs.
• JWPF 8P connectors — 2 pcs.

Attention!
Wire for Hall sensors or Encoder is not included in the kit and is purchased separately. You can choose additional wiring in the "Accessories" section on the website

Important information:

• How to screw the wires to the controller. Torque 6Nm MAX for all screws.
• How to assemble the JWPF connector.
• Connection diagram of P24F controller.

Worldwide shipping cost via DHL:
For one kit — $90.
For two kits and more — ask.

Plug & Ride Kit for Sur-Ron Light Bee. Up to 30% more power оn standard 60V battery and up to 300% on 72V battery. Installation guide.

Сonnection to the standard wiring instead of the factory controller. All systems (kickstand, fall sensor, throttle, and key) will work. Headlights, brake light, and turn signals on road versions also will work. You can use "Eco/Sport" switch to set it up two different power modes. But the speedometer on this switch will not work, this function will be performed on our On-board computer.

In the kit:

• Nucular controller P24F with the latest firmware for Sur-Ron.
• On-board computer with a mount for fork stem.
• CAN-wire 120 cm (47.2 inch) for On-board computer.
• Wiring with connectors for connecting to Sur-Ron.
• Phase wire extensions with bolts and nuts.
• Plastic adapter for mounting.

In stock.

Attention!
The firmware for a standard 60V battery is installed on the controller. If you have a more powerful battery, you need to change its settings in the Controller > Battery section and set other power modes in the Controller > Control Modes menu.

We also recommend adding the Universal thumb lever for regen (NUCTHR) to the kit.

Worldwide shipping cost via DHL:
For one kit — $90.
For two kits and more — ask.

Plug & Ride Kit for Talaria Sting MX3/MX4. Up to 30% more power оn standard 60V battery and up to 300% on 72V battery. Installation guide. The maximum power on the standard battery on the MX4 is 12kW.

Сonnection to the standard wiring instead of the factory controller. All systems (kickstand, fall sensor, throttle, and key) will work. Headlights, brake light, and turn signals on road versions also will work. You can use the switch on the right side to set it up different power modes. The Talaria factory display replace by our On-Board Computer.

In the kit:

• Nucular controller P24F with firmware for Talaria.
• On-board computer with a mount for fork stem.
• CAN-wire 120 cm (47.2 inch) for On-board computer.
• Wiring with connectors for connecting to Talaria.
• Plastic adapter for mounting with bolts.

In stock.

Attention!
The firmware for a standard 60V battery is installed on the controller. If you have a more powerful battery, you need to change its settings in the Controller > Battery section and set other power modes in the Controller > Control Modes menu.

We also recommend adding the Universal thumb lever for regen (NUCTHR) to the kit.

Worldwide shipping cost via DHL:
For one kit — $90.
For two kits and more — ask.

Plug & Ride Kit for Talaria XXX. Up to 30% more power оn standard 60V battery and up to 300% on 72V battery. Installation guide.

Сonnection to the standard wiring instead of the factory controller. All systems (kickstand, throttle, and key) will work. Headlights, brake light, and turn signals on road versions also will work. You can use factory switch to set it up two different power modes.

In the kit:

• Nucular controller P24F with the latest firmware for Talaria XXX.
• On-board computer with a mount for fork stem.
• CAN-wire 120 cm (47.2 inch) for On-board computer.
• Wiring with connectors for connecting to Talaria XXX
• Plastic adapters for mounting with bolts and nuts

In stock.

Attention!
The firmware for a standard 60V battery is installed on the controller. If you have a more powerful battery, you need to change its settings in the Controller > Battery section and set other power modes in the Controller > Control Modes menu.

We also recommend adding the Universal thumb lever for regen (NUCTHR) to the kit.

To configure the controller, display statistics and parameters. Manual

In the kit:

• On-board computer 2.0 with the latest firmware in English.
• GoPro fork mount.
• PHD 2.0 4P connector — 4 pcs.
• PHD 2.0 6P connector — 1 pcs.
• PHD 2.0 8P connector — 1 pcs.
• Pins for crimping — 26 pcs.

If you don't have a crimping tool need to order "Crimped wires for the Display".

In stock.

Read about the differences between versions of on-board computers here.

Also, you can add a USB wire for On-board computer for charging your gadgets (NUCUSB).

Lighting control controller. A controller designed to control turn signals, brake lights, headlights or LED strips. The board has three CAN inputs and can function as a CAN splitter. Manual.

In the kit:

• uLight controller with the latest firmware.
• PHD 2.0 4P connector — 4 pcs.
• PHD 2.0 6P connector — 4 pcs.
• Power wires 22AWG 2x200 mm with connectors XH 2.54 2P — 6 pcs.
• Power wires 22AWG 300 mm with pins, crimped on both sides — 8 pcs.
• Wires 26AWG 300 mm with pins, crimped on both sides — 20 pcs.

In stock.

We recommend adding a CAN wire for connection uLight to CAN-bus. Check in the Accessories section.

Module for connecting the controller via CAN line to the USB port for setting up and updating the firmware via a Windows computer. Software and manual.

Preorder.

Wire for connection to the CAN-bus of the On-board computer, uLight, BMS and other devices from Nucular. Crimped on both sides with PHD 2.0 6P connectors. Three different lengths.

Attention!
Not suitable for connecting a Controller P24F to other Nucular devices. For this purpose, use the CAN wire PHD-JWPF.

Wire for connection to the CAN-bus of the Controller P24F. Crimped from one side with PHD 2.0 6P connector and JWPF 6P on the other. Three different lengths.

Attention!
The PHD-JWPF CAN wire 120 cm (47.2 inch) long is supplied with the Controller P24F. If you ordered a controller, you do not need to order a CAN wire separately.

Wire for throttle and brake input for Controller P24F. JWPF 6P connector on the controller side and two JWPF 3P connectors on the other side. Wires 22AWG. Length with connectors 28 cm (11.02 inch).

This wire is required if you connect all peripherals directly to the Controller P24F, and not to the On-board computer (default connection).

You can also purchase a mating part for this wire, see "Mating part TH/BK".

JWPF 3P connector on one side and stripped wires on the other. The wires are 22AWG. Length with connectors 23 cm (9.05 inch). Included 2 pcs.

Kit for connecting the Controller P24F to the standard Sur-Ron Light Bee wiring.

If you ordered the Kit for Sur-Ron Light Bee, you do not need to order these wires separately.

ABS plastic adapter for installing the Controller P24F on the Sur-Ron Light Bee.

In the kit:

• Plastic ABS adapter with mounts.
• Mounting screw kit.
• Phase wires extensions with heat shrink and bolts for connection.

Attention!
If you ordered the Kit for Sur-Ron Light Bee, you do not need to order this adapter separately.

Kit for connecting the Controller P24F to the standard Talaria Sting wiring.

If you ordered the Kit for Talaria Sting, you do not need to order these wires separately.

Adapter for installing the P24F controller on the Talaria Sting. The adapter is printed on a photopolymer 3D printer, sanded and painted with black paint. Factory quality ABS adapter will be available for order ~ starting September 15

In the kit:

• Plastic adapter with mounts.
• Mounting screw kit.

Attention!
If you ordered the Kit for Talaria Sting, you do not need to order this adapter separately.

On one side a JWPF 8P connector for connecting to the Controller P24F, on the other side there is a waterproof 8P connector. Wires 22 AWG. Length with connectors 29 cm (11.4 inch).

Attention!
The mating part for the connector is not included, you can purchase it separately. Part number DJ7081Y-2.3-11.

On one side a JWPF 8P connector for connecting to the Controller P24F, on the other side there is a waterproof 6P connector. Wires 22 AWG. Length with connectors 29 cm (11.4 inch).

Attention!
The mating part for the connector is not included, you can purchase it separately. Part number DJ7061Y-2.3-11.

For connecting multiple Controllers, BMS or other Nucular devices to a CAN bus. 4 ports, PHD 2.0 6P connectors. Dimensions 16x22 mm.

30V, opto-isolated, used when connecting a powerful load to the controller (stop lights or fans).

Wiring diagram for brake lights and fans.

Wires for soldering, 12 pcs. Wires 26 AWG. Length 20 cm (7.87 inch). Crimped with pins on both sides.

By default, all control devices (thumb throttle, brake levers, switches, etc.) are connected to the ports located on the back of the On-Board Computer. To access, you need to unscrew five screws and remove the plastic cover. For connection, PHD 2.0 connectors and crimp pins are used, which are included in the kit. If you do not have a crimping wire tool, for example, SN-2549, you can use these crimped wires

It is necessary to cut them in the middle, solder them to the wires of the throttle or brake handles, and insert the crimped ends into the PHD 2.0 connectors (include in the kit of On-board computer) and connect them to the On-board computer.

Temperature sensors NTC10k B: 3950 for electric motor. Includes 2 pcs.

The wire is 40 cm (15.74 inch) long. It is crimped with a PHD 2.0 4P connector for connection to the On-board computer in the THR (gas) or BRK (brake) ports.

For 24F and P24F controllers. Wires 10AWG. Length with connectors 55 cm (21.65 inch). XT90E-M connector on one side, two 8-6S terminals on the other.

In the kit:

• Cable with connectors.
• Cap for XT90E-M connector.
• Two screws with nuts to secure the cap.

Length with connectors 22 cm (8.66 inch). Crimped with PHD 2.0 4P connector. Connects to the USB port on the back side of the On-board computer 1.0 and 2.0.

In the kit:

• PHD 2.0 4P connector — 4 pcs.
• PHD 2.0 6P connector — 4 pcs.
• Power wires 22AWG 2x200 mm with connectors XH 2.54 2P — 6 pcs.
• Power wires 22AWG 300 mm with pins, crimped on both sides — 8 pcs.
• Wires 26AWG 300 mm with pins, crimped on both sides — 20 pcs.

Attention!
If you have already ordered a uLight controller, then you do not need to buy this set separately, it will be included.

Board for the QS138 motor, which allows you to switch to an ABZ + PWM encoder for 1024 pulses.

In the kit:

• Encoder board.
• Wires with connector.
• Two magnets of different thicknesses.
• Plastic adapter for installation.

Video installation guide.

Capacitor block for connecting the solar panel to the controller and charging the ebike battery using MPPT technology and motor charging function. To use the module, you need to update the controller firmware to v0.8.12 and higher.

To connect the module to the 24F and P24F controllers, you can purchase a Wire for charging (code NUCTHMW).

For version 1.0. Shockproof plastic. In case of damage to the case of the On-Board Computer, you can replace the entire case yourself.

In the kit:

• The rear part with a button and an SD card cap.
• Cover for connection ports for the rear part.
• Front part with glass (pasted separately).
• Buttons and button pushers.
• Screws for assembling — 7 pcs.

Read about the differences between versions of On-board computers here.

For version 1.0. Transparent plastic. To replace damaged glass on the On-board computer. Attaches with 3M double-sided tape (included). The screen has a protective film that can be removed after installation.

Read about the differences between versions of On-board computers here.

For version 2.0. Shockproof plastic. In case of damage to the case of the On-Board Computer, you can replace the entire case yourself.

In the kit:

• The rear part with a button and an SD card cap.
• Cover for connection ports for the rear part.
• Front part with glass.
• Buttons and button pushers.
• Screws for assembling — 7 pcs.

Read about the differences between versions of On-board computers here.

For version 2.0. Transparent plastic. To replace damaged glass on the On-board computer. Attaches with double-sided tape (included). The screen has a protective film that can be removed after installation.

Read about the differences between versions of On-board computers here.

For versions 1.0 and 2.0. To replace a damaged On-board computer LCD module. To replace it, disconnect the LCD module cable from the PCB and unsolder two contacts of the damaged LCD module.

Silicone. To replace damaged buttons On-board computer 1.0

To replace damaged button pushers On-board computer 1.0. You can also 3D print them yourself. Link to STEP file.

Kit with mounting and connectors for On-board computer version 1.0 and 2.0

In the kit:

• Mounting for the fork stem.
• PHD 2.0 4P connector — 4 pcs.
• PHD 2.0 6P connector — 1 pcs.
• PHD 2.0 8P connector — 1 pcs.
• Pins for crimping for 26 AWG wire— 26 pcs.

If you don't have a crimping tool need to order "Crimped wires".

Attention!
If you have already ordered an On-board computer, then you do not need to purchase this items, it will be included in the kit.
